EN19 Plate Stockist and Suppliers (708M40 / 709M40)
Textron Steel and Alloys is a leading EN 19 Plate Stockist, EN19 Plate Suppliers and EN19 Plate Manufacturer. EN19 also known as 708M40 / 709M40 and AISI 4140 come regarded in the toughened as moved or even T condition. We also offer EN 19 Seamless Pipes Manufacturer, EN 19 Pipes, Seamless Pipes Stockist, Supplier, Exporter, EN19 Seamless Rectangular Pipes, EN19 Seamless Pipes Square Pipes Supplier, EN19 Seamless Round Pipes Supplier, Manufacturers, Exporters. We can offer EN19 Plate in widths, squares, and pads from stock. It is fame for its wear resistance properties and where High Quality Properties is required. Suitable for apparatuses, shafts, axles and so forth.
We are putting forth a broad scope of Steel Plates EN-19 Grade, which is sans short coming. These Steel Plates EN 19 Grade find boundless application in different commercial enterprises, for example Vehicles Fabricating, Pressing Vessels and Compartment and Development Segment, among others. Our scope of Steel Plates EN19 Grade is accessible at most focused costs.
The EN19 Grade Steel Plate that we offer exactly matches the desirable plates of such kinds. It is of the best quality and endowed with high tensile strength. We are working in full throttle to make it available to the length and breadth of the country and abroad. We are one of the eminent Stockist, Exporters and Suppliers of EN19 Grade Steel Plate from Mumbai, India.
En Series/ EN19 Steel Plate
En Series/ EN19 Steel Plate Stockist India
En Series/ EN19 Steel Plate Suppliers India
Equivalent Grades :
|AISI SAE||UNS No.||Hardness||Tensile Strength||Yield Strength|
|4140 Steel Plate Flat Steel Bar EN 19 PLATES||G41400||Bhn 195+ RC 22+||As Rolled Condition||As Rolled Condition|
Chemical Composition of EN19 Plates :
|C||Mn (max)||P (max)||S (max)||Si||Cr||Mo|
|0.38 – 0.43||0.75 – 1.0||0.035||0.04||0.15 – 0.30||0.8 – 1.1||0.15 – .25|
The EN19 steel plate equivalent grades are AISI 4140 plate, DIN 1.7225/42crmo4 plate.
There are some differences between all in chemical composition as below:
Key features of EN19 Plate:
• EN19 Plate is a High quality alloy steel
• EN 19 Plate is known as High tensile steel
• EN19 Steel Plate has Good ductility and shock resistance
• Good wear resistance
• EN19 Sail Hard steel plate can be induction hardened
AISI 4140 Plates / EN19 Plate Uses :
• Oil & Gas Industries
EN19 was originally introduced for the use in the machine tool and motor industries for gears, pinions, shafts, spindles and the like. Later its applications became much more extended and it is now widely used in areas such as the oil and gas industries. EN19T is suitable for applications such as gears, bolts, studs and a wide variety of applications where a good quality high tensile steel grade is suited.
Tooling, machine plates, gears, shafts, sprockets, Special Machine Parts Molds, Metal Stamping, Tool & Die, Shredders, Automotive, Oil & Gas Industries, Machine Shop, Paper Mills.
Pre heat carefully, then raise temperature to 850-1200oC for forging. Do not forge below 850oC. After forging cool slowly in still air.
Heat the EN19T slowly to 680-700oC. Cool in air.
This steel grade is commonly supplied ready heat treated. If further heat treatment is required annealed EN19 should be heated slowly to 860-890oC and after adequate soaking at this temperature quench in oil. Temper as soon as tools reach room temperature.
Heat carefully to a suitable temperature selected by reference to a tempering chart or table. Soak at the temperature for 2 hours per 25mm of ruling section, and then allow cooling in air. Tempering between 250-375oC is not advised as tempering within this range will reduce the impact value.
Heat Treatment :
Heat treatment temperatures, including rate of heating, cooling and soaking times will vary due to factors such as the shape and size of each steel component. Other considerations during the heat treatment process include the type of furnace, quenching medium and work piece transfer facilities. Please consult your heat treatment provider for full guidance on heat treatment of EN19 alloy steel.
Also Known as :
BS 970 1955 EN : EN19
AISI/SAE : 4140
Werkstoff : 1.7225
Comparison of steel grades :
|BRITISH BS 970:1991||709M40T||AISI||4140|
|BRITISH BS 970:1955||EN19T||DIN||42CrMo4|
|EUROPEAN STEEL NO.||1.7225||GB||42CrMo|
|EUROPEAN STEEL NAME||42CrMo4||SS||2244|
People also Search as :
|EN19 Plates Stockiest||EN19 Sheets Stockiest|
|EN19 Plates Suppliers||EN19 Sheets Suppliers|
|EN19 Plates Exporters||EN19 Sheets Exporters|
|EN19 Plates Traders||EN19 Sheets Traders|
|EN19 Plates Distributors||EN19 Sheets Distributors|
|EN19 Plates Stockist||EN19 Sheets Stockist|
|EN 19 Plates Stock Holder||EN 19 Sheets Stock Holder|
|EN19 Authorised Stockist||EN19 Authorised Stockist|
|EN19 Plates Mumbai Stockists||EN19 Sheets Mumbai Stockists|
|EN19 Plates Maharashtra||EN19 Sheets Maharashtra|
|EN19 Plates India||EN19 Sheets India|
|EN19 Plates Mumbai Supplier||EN19 Sheets Mumbai Supplier|
|EN19 Uttam Make Plates||EN19 Uttam Make Sheets|
|Uttam Plates Stockist||Uttam Sheets Stockist|
|Authorised Stockist of EN19 Plates||Authorised Stockist of EN19 Sheets|
4140 PH or 4140 PREHARD has the same industry standard chemistry as above.
4140 Steel Bar 4140 HR Plate Oil Quenched & Tempered 4140 PH has a standard, industry recognized Rockwell C Hardness rating of 28 – 32.
Most sources recognize and tend to prefer quoting and requesting the Rockwell C Scale. 4140PH ranges from Brinell Hardness 270 – 300.
Thick 4140 AN (in the Annealed condition) is flame cut, then Annealed onsite in our furnace. Annealing greatly improves Grinding and Machining. Parts can be returned to the standard hardness when followed by a Normalize & Specific Tempering heat treatment process.
